یو پی اس schneider electric مدل SMT1000RMI2U

توضیحات محصول

APC Smart-UPS, Line Interactive,
1000VA, Rackmount 2U, 230V, 4x
IEC C13 outlets, SmartSlot, AVR,
LCD
Physical
Number of rack unit 2U
Number of cables 1
Colour Black
Height 8.5 cm
Width 48 cm
Depth 47.5 cm
Net weight 28.18 kg
Mounting location Front
Mounting preference Lower
Mounting mode Rack-mounted
Two post mountable 0
USB compatible Yes
Input
Main Input Voltage 230 V
Other Input Voltage 220 V
240 V
Input Connection Type IEC 320 C14
Input voltage limits 151...302 V adjustable
160...286 V
Network frequency 50/60 Hz +/- 3 Hz auto-sensing
Output
Main Output Voltage 230 V
Other Output Voltage 220 V
240 V
Rated power in W 700 W
rated power in VA 1000 VA
output connection type 4 IEC 320 C13
2 IEC Jumpers
Harmonic distortion Less than 5 % at full load
Maximum configurable power in
VA
1000 VA
Maximum configurable power in
W
700 W
Transfer time 2 ms typical
UPS type Line interactive
Wave type Sine wave
Output frequency 47...53 Hz for 50 Hz nominal sync to mains
57...63 Hz for 60 Hz nominal sync to mains
